If you are experiencing an operational issue with your range and would like to request service, please fill out the online service request form below or contact the La Cornue National Service Center: 1–877-522‑6768



A service representative may contact you to get a better understanding of your problem. La Cornue Ranges are extremely reliable, so most times it just takes time to get familiar with the way your La Cornue Range works.

Request Service or Repair





REQUEST PARTS



Part requests could be purchased through our National parts supplier, Coast Parts and Supply:

US Residents: 1–800-821-0244

Canadian Residents: 626-579-1500





The most common parts needed for replacement are:

Oven Lightbulb

Château: order Part No. 06FPGV01-100



CornuFé 110:  Models before Serial No. 196000, order Part No. P033451 and for Models after Serial No. 196000, order Part No. P067490

CornuFé 90:  Models before Serial No. 185000, order Part No. P033451 and for Models after Serial No. 185000, order Part No. P067490

Rubber Grate Feet


For all Château and CornuFé Ranges:  order Part No. P029037 (individual rubber feet) or Part No. A048188 (rubber feet kit includes 20 rubber feet + a small tube of black silicon)


Note:  When replacing the rubber feet, apply the black silicon to the grate’s hole before installing the foot.  It is advised to use safety gloves or finger protectors when touching the silicon.  Position the grates back on the rangetop and do not move them for 24 hours to allow the silicon to dry completely.





LOCATING THE MODEL & SERIAL NUMBERS



CHÂTEAU OWNERS

There are two ways to find this information. Each Range has a warranty card included with the manuals; this card contains the Model and Serial numbers. If you have misplaced the warranty card, model and serial numbers are also printed on the range itself. To locate, simply open the left-hand storage drawer to find an ID plate with the inscribed information. For older Chateau models, the plate can be found on the inside of the left-hand oven control door.


CORNUFÉ OWNERS

There are two ways to find this information: on the front cover of the user manual or on the range itself. The user manual should have a silver sticker on the front cover with a 10-digit number. Serial numbers start with 7 or 8. The model number will start with C, eg, C1LF. If you have misplaced the User Manual, you may also find the serial number on an ID tag that is located underneath the storage drawer. To remove the storage drawer, please refer to the image below. There are 4 black screws and washers that need to be removed by using Phillips #2 Screwdriver. Once removed, put it in a safe place and lift the drawer off the rails.
